DEM 6e
Compact electric shrink-wrapping machines combining an L-sealer and a shrink tunnel. Sealing frames of 800 x 650 mm.
En savoir plusDescription
The DEM 6e semi-automatic compact shrink-wrapping machines are L-seal machines with an integrated tunnel, ideal for medium-speed production. These packaging machines allow you to wrap all kinds of products: books, detergents, CDs, puzzles, eggs, magazines, electronic devices, dried fruits, etc., with a medium rate of up to 15 cycles per minute.
The operation is simple: the product is placed between the two sides of the folded film and positioned by the operator under the sealing frame. The sealing arm electrically lowers and performs an 'L'-shaped seal/cut. Once the arm lifts, the conveyor moves the product towards the shrink tunnel.
Features :
- The sealing bar movement is powered by an electric motor.
- In automatic mode, the sealing bar lowers based on a predefined cycle time.
- In manual mode, the sealing bar lowering is pushed by a button.
- Sensor for obstacle detection and automatic cycle stop for enhanced operator and product safety.
- Adjustable tunnel fan power to optimize shrinkage.
- Adjustable tunnel conveyor speed.
- Heat adjustment with PID digital control.
- Adjustable air circulation via side flap handles.
- Delayed stop at set temperature of 70°C.
- Tunnel overheat control system with automatic shutdown.
- The conveyor heights can be adjustable which accommodates variable products.
- The fixed height products exit with reguardless of its adjustment.
- Adjustable sealing time based on film thickness.
- Temperature, time, and speed settings are adjustable with the help of the digital control panel.
Advantages :
- Removable waste tray.
- Welded steel construction on a single frame for optimized space.
- Sealing system with a unique heated blade.
- Constant temperature control of the sealing wire increases sealing quality, process precision, and durability.
- Machine equipped with 4 swivel casters with brakes.
- 500mm long roller conveyor with removable stop.
- Full opening for easy access to the electrical cabinet.
|
Reference |
DEM 6e |
|
Sealing arm opening |
250 mm |
|
L-sealing size |
800 x 650 mm |
|
Max bag dimensions |
600 x 800 x 300 mm* |
|
Max product height |
150 mm |
|
Maximum film width |
700 mm |
|
Maximum roll diameter |
250 mm |
|
Film type |
POF 7-37µ / PEBD |
|
Power supply |
400 V 3PH + T + N - 21A |
|
Consumption |
10kW |
|
Machine weight (Net / Gross) |
735 / 840 Kg |
|
Overall dimensions (A x B x C) |
126 x 355 x 157 cm |
* These maximum dimensions cannot be achieved simultaneously.
