Professional dual-active impulse sealer with pneumatic closure for thick bags up to 1320mm wide.

Validatable machine with control of sealing time, sealing temperature, cooling, and pressure.

En savoir plus

Description

The IST 132020 MED PLUS ensures high-quality packaging results for the medical sector.

This validatable tabletop impulse sealer comes standard with a user-friendly touchscreen interface and is suitable for sealing a wide variety of films. The operator can store up to 50 programs, ensuring ideal preset parameters for each packaging.

The robust stainless steel construction and powerful dual-active sealing bars allow effortless sealing of thick and special films, providing a fully airtight 8 mm seal. With the IST MED PLUS series, you get maximum control over sealing parameters (sealing temperature, cooling temperature, sealing time, and pressure), even during intensive use, making every seal 100% reliable!

This sealer is suitable for the medical, pharmaceutical, chemical, technological, and industrial sectors.

Main features:

- Dual-active sealing for better results on complex films

- Robust construction with stainless steel covers

- Pneumatic closure and locking of the sealing bars for very high sealing pressure

- 45 mm jaw opening for easy bag placement

- Parameter control via touchscreen

- Electric foot pedal closure

- Ability to store 50 different work cycles

- Sealing temperature validation

- USB port and data recording

- 3 access levels for parameters: operators, supervisors, administrators

A wide range of options has been developed to meet various applications in different sectors.

1320 ISTMEDWB
11433
Data sheet
Reference
1320 ISTMEDWB
Sealing length
1320 mm
Sealing width
8 mm
Maximum film thickness
2 x 400 microns
Coating
Stainless steel
Sealing type
Impulse (biactive)
Integrated knife
En Option (coupe de 1245 mm)
Pedal operated
Yes
Validation
Yes
Protection IP
IP 20
Voltage
230 V mono
Consumption
2600 W

Support à roulettes


Support de sacs réglable (en complément du Support à roulettes)


Plateau de travail réglable (en complément du Support à roulettes)


Support de sacs à rouleaux libre (en complément du Support à roulettes)


Tendeur de sacs


Système de coupe (coupe limité à 455 mm)


Écran tactile incliné


Protection des commandes en plexiglas avec clef

Machine anti-static (ESD)

Pédale pneumatique (pédale électrique IP20 en standard)

Pédale électrique IP65 (IP20 en standard)

Bouton de démarrage sur machine

Configuration couche épaisse

Soudure 5 mm (8 mm en standard)

Soudure 10 mm (8 mm en standard)

Capteurs de sécurité supplémentaires

Lecteur de code barre

Étiqueteuse CAB MACH

Erreur maximale tolérée

Écran tactile incliné

Roues en polyamide

Machine en 115 volt

Machine pauvre en composant silicone
