Dempack H20
zoom_out_map
chevron_left chevron_right

Dempack H20

21120
21120
98 kg
Garanties sécurité Politique de livraison Politique retours

Compact shrink chamber machine for small and medium productions (200 to 300 cycles per hour). Sealing frame size: 440 x 300 mm.

En savoir plus
€3,150.00 (VAT incl.) €3,150.00 (VAT excl.)
VAT excluded Livraison sous 3-4 jours
check En Stock

Description

The DEMPACK H20 shrink chamber machine is ideal for shrink-wrapping small productions. This machine cleverly combines the L-sealing operation with the film shrinkage around the products. The operator places the product inside the film pocket on the loading tray, then pulls the film and positions the product in the chamber. The operator manually lowers the cover, which is held closed by electromagnets. The film shrinkage occurs simultaneously with the sealing operation. Shrinkage is achieved immediately through hot air circulation around the product. At the end of the process, the chamber automatically opens, allowing the operator to retrieve the wrapped product. This machine is designed for packaging a wide variety of products, in both the food and industrial sectors. It is compatible with most shrink films available on the market.

21120
21120
98 kg
Data sheet
Coating
Epoxy
Protection IP
IP 20
Voltage
230 V mono
Consumption
1650 W
Weight Gross
98 kg
Packaging size
114 x 76 x 68 cm
L – Sealer Size
440 x 300 mm
Maximum Product Length*
410 mm
Maximum Product Width*
250 mm
Maximum Product Height*
210 mm
Film Type
Polyolefin
Maximum Film Width
450 mm
Maximum Roll Diameter
250 mm
Plateau de conditionnement en inox.
